| Business Type | Exporter |
|---|---|
| Country of Origin | India |
| Color | Available in Different Colors |
| Preferred Buyer From Location | Worldwide |
| Packing Type | Export Standard Packing or as required. |
| Delivery Time | As required |
| S.N | TECHNICAL SPECIFICATIONS | SIZE / QUANTIY |
| 1 | LOWER FRAME (BOTTOM CHASSIS CHANNEL) | MADE FROM 125 X 65 X 5 MM MS CHANNEL APPROX. 2100 MM LENGTH |
| 2 | CUTTING ASSEMBLY | 4 NOS FEED IN GROLLERS & MOUTH SIZE275 MM WIDE |
3 |
FEEDING SYSTEM | CONVEYOR TYPE FEEDER WITH FORWARD AND REVERSE GEAR CONTROL CONNECTED WITH 4 NOS JOINTS. THE FEEDER IS COVERED NEAR BY FEED ROLLER SIDE |
| 4 | FLY WHEEL | MADE FROM MS IRON PLATE WHICH DIAMETER 825 MM |
5 |
CUTTING BLADES | 4nos. CUTTING BLADES MADE FROM CARBON STEEL THICKNESS 2.5 mm. WHICH CAN BE ADEJESTABLE IN 3 &2 BLADES. |
6 |
GEAR BOX | PROVISION OF THREE FORWARD AND ONE IS REVERSE GEARIN THE MACHINE AND PROVISION OF LUBRICATION IN ALL THE ROTATING PARTS. AND GEAR CHAIN IS COVERED FROM 1.6 MM. THICK M.S. IRON SHEET |
7 |
BEARING AND PEDSTALE | 3nos. PEDSTALE IN MAIN SHAFT AND 2nos. PEDSTALE IN LOWER PULLY AND 1nos. IN GEAR BOX |
| 8 | BALANCE WHEEL | MADE FROM CAST IRON, DIAMETER IS 75mm. & THICKNESS 75mm. TOP. |
9 |
DRIVEN PULLY | THREE GRIP PULLY MADE FROM CAST IRON UPPER PULLY DIAMETER: - 225mm. LOWER PULLY DIAMETER: - 250mm. |
| 10 | MAIN SHAFT | DIAMETER 65mm. |
| 11 | V-BELT | MADE FROM HINDON OR EQUIVALENT. |
| 12 | P.T.O. SHAFT | GOOD QUALITY CROSS FITTED 90° |
| 13 | TRACTOR POWER CAPACITY | 30 Hp. or ABOVE CONNECTING TO THE TRACTOR. |
14 |
CUTTING CAPACITY | THIS MACHINE IS SUITABLE FOR CUTTING BOTH TYPE CHAFF GREEN CHAFF & DRY CHAFF. GREEN CHAFF: 2500 Kg./hr. TO3500Kg./Hr. DRY CHAFF:2000 Kg./hr. TO 2500Kg./Hr. AND IT DEPENDS ON THE INPUT FEED AND CHAFF CONDITION. |
| 15 | CHAFF CUTTING SIZE | 5mm. TO 10mm. |
| 16 | FEEDING (CROP/CHAFF) MATERIAL | MILLET, SORGUM, MAIZE &PADDY STRAW ETC |
| 17 | TRANSPORTATION WHEEL/TYRE | 6.00 X 16 |
| 18 | SPEED | MULTI SPEED WITH 540 rpm. / 1000 rpm. TRACTOR. |
| 19 | LINKAGE | AT TRACTOR’S TROLLEY HOOCK |
20 |
SAFTEY GUARD/COVER | ALL THE MOVABLE PARTS ARE COVERED FROM 1.6mm THICK M.S. IRON SHEET AS PER BIS STANDERD |
| 21 | FEETING ACCESSORIES | MACHINE COMPLETELY FITTED FROM NUT, BOLTS AND WASSERS TO MAKE IT FOLDING |
22 |
OVER ALL DIAMENSION | LENGTH: - 3300mm. WIDTH: - 1200mm. HIGHT:- 2100mm. |
| 23 | OVER ALL WEIGHT | 900Kg. APPROX. |
We endeavor to provide the clients with the best materials and timely deliver to their maximum satisfaction.
